1700MHz to 3000MHz High-Linearity,
Low LO Leakage Base-Station Rx/Tx Mixer
AC ELECTRICAL CHARACTERISTICS (Upconverter Operation)
(MAX2043 Typical Application Circuit , V CC = +4.75V to +5.25V, P LO = -3dBm to +3dBm, P IF = 0dBm, f RF = 1700MHz to 3000MHz,
f LO = 1900MHz to 3000MHz, f IF = 200MHz, f RF = f LO - f IF , T C = -40 ° C to +85 ° C, unless otherwise noted. Typical values are at V CC =
+5V, P IF = 0dBm, P LO = 0dBm, f RF = 2170MHz, f LO = 2260MHz, f IF = 90MHz, T C = +25 ° C, unless otherwise noted.) (Note 3)
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
Input Compression Point
IP1dB
23
dBm
Two tones:
f IF1 = 90MHz,
3rd-Order Input Intercept Point
IIP3
f IF2 = 91MHz,
P IF = +5dBm/tone,
28
dBm
f LO = 2230MHz,
P LO = 0dBm
LO ± 2IF Spur
LO ± 3IF Spur
Output Noise Floor
LO - 2IF
LO + 2IF
LO - 3IF
LO + 3IF
P OUT = 0dBm
60
60
67
69
63
64
-160
dBc
dBc
dBm/Hz
Note 1: All limits reflect losses of external components. Output measurement taken at IF port of Typical Application Circuit .
Note 2: The lower IF frequency limit of 0MHz is limited by the external IF transformer.
Note 3: Measured with external LO source noise filtered so its noise floor is not a contributor. Measured with: f RF = 2000MHz,
f BLOCKER = 2100MHz, f LO = 2190MHz, using a 190MHz SAW filter on the IF port. This specification reflects the effects of
all SNR degradations in the mixer, including the LO noise as defined in Maxim Application Note 2021.
Note 4: Maximum reliable continuous input power applied to the RF or IF port of this device is +15dBm from a 50 ? source.
Note 5: Typical Operating Characteristics show LO drive extended to +6dBm
Note 6: Measured IF port at IF frequency. f LO1 and f LO2 are offset by 1MHz.
Note 7: IF return loss can be optimized by external matching components.
Typical Operating Characteristics
(MAX2043 Typical Application Circuit , C2 not installed, RFTAP = GND, V CC = +5.0V, P LO = 0dBm, LOSEL = “ 0 ” (LO2 selected), P RF =
0dBm, f LO > f RF , f IF = 200MHz, unless otherwise noted.)
Downconverter Curves
CONVERSION LOSS vs. RF FREQUENCY
CONVERSION LOSS vs. RF FREQUENCY
CONVERSION LOSS vs. RF FREQUENCY
9
8
T C = +85°C
9
8
9
8
7
7
7
6
V CC = 4.75V, 5.0V, 5.25V
6
T C = -40°C
T C = +25°C
6
P LO = -3dBm, 0dBm, +3dBm
5
5
4
5
4
4
3
1500
1700
1900
2100
2300
1500
1700
1900
2100
2300
1500
1700
1900
2100
2300
RF FREQUENCY (MHz)
RF FREQUENCY (MHz)
RF FREQUENCY (MHz)
4
